GIGABYTE B760M GAMING plus WIFI DDR4 LGA 1700 Intel B760 M-ATX Motherboard With

GIGABYTE B760M GAMING plus WIFI DDR4 LGA 1700 Intel B760 M-ATX Motherboard With

$182.14
$0.00 $182.14
Sale Sold out
eBay

Learn more about GIGABYTE B760M GAMING PLUS WIFI DDR4

Model
Brand
GIGABYTE
Model
B760M GAMING PLUS WIFI DDR4
Supported CPU
CPU Socket Type
LGA 1700
CPU Type
Celeron / Intel Core 12th Gen (LGA 1700) / Intel Core 13th G / Intel Core 13th Gen (LGA 1700) / Intel Core 14th Gen (LGA 1700) / Pentium Gold
Chipsets
Chipset
Intel B760
Memory
Number of Memory Slots
4x288pin (DDR4)
Memory Standard
DDR4 3200
Maximum Memory Supported
128GB
Channel Supported
Dual Channel
Memory Feature
Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/3200/3000/2933/2666/2400/2133 MT/s memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Expansion Slots
PCI Express 4.0 x16
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
PCI Express x1
2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
Storage Devices
SATA 6Gb/s
4 x SATA 6Gb/s
M.2
1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
SATA RAID
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Onboard Audio
Audio Channels
7.1 Channels
Onboard LAN
Max LAN Speed
1Gbps
Wireless LAN
Wi-Fi 802.11 ax
Bluetooth
BLUETOOTH 5.3
Rear Panel Ports
Back I/O Ports
2 x USB 2.0/1.1 ports
1 x PS/2 keyboard/mouse port
2 x SMA antenna connectors (2T2R)
1 x DisplayPort
1 x HDMI port
3 x USB 3.2 Gen 1 ports
1 x RJ-45 port
3 x audio jacks
Internal I/O Connectors
Onboard USB
1 x USB Type-C header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
Other Connectors
1 x CPU fan header
3 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only)
1 x serial port header
1 x parallel port header
1 x S/PDIF Out header
1 x Q-Flash Plus button
1 x reset jumper
1 x Clear CMOS jumper
Physical Spec
Form Factor
Micro ATX
Dimensions (W x L)
9.6" x 9.6"
Power Pin
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
Windows Compatibility
Windows 11
Supported
Features
Features
Support for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus

H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control
